Highlights

• MJPEG, CMOS
• Two-way audio, Remote Pan/Tilt rotate, Indoor
• 16 LED, IR distance 10~15M.
• Wireless(Wi-Fi/802.11/b/g), Free Factory DDNS
• Motion detection, email alert, FTP upload
• Iphone, 3G phone, Smartphone supported
• Multi-language, Firefox, Safari, Google browser
• Product Size: 100*100*120mm(GW:0.8kg)

Features

• Powerful high-speed video protocol processor
• MJPEG video compression
• Support wireless network (Wi-Fi/802.11/b/g)mobile
• Support two-way audio function
• High-sensitivity CMOS sensor
• Resolution: 640 x 480(VGA), 320 x 240(QVGA)
• Video Frame Rate: 30fps (QVGA), 15fps (VGA)
• Minimum Illumination: 0.5Lux @ F2.0
• IR night vision (Range: 8~12m)
• Remote Pan/Tilt rotate (Horizontal: 270°, Vertical: 120°)
• Supports control P/T through IP network
• Supporting image snapshot
• Built-in 10M/100M auto MDI/MDIX Ethernet interface
• Frame ratio or Bandwidth can be adjusted
• Light Frequency: 50Hz, 60Hz or Outdoor
• Multi-level user’s management and passwords definition
• Built-in Web server, supports remotely viewing and/or management the camera form a standare Web browser on any computer, anywhere, and at anytime
• Supporting Dynamic IP (DDNS) and UPnP LAN and Internet (ADSL, Cable Modern), Free DDNS Bound
• Giving alarm in cause of motion detection
• Supporting image snapshot
• Supporting multiple network protocols: HTTP/TCP/IP/UDP/STMP/DDNS/SNTP/DHCP/FTP
• Built-in RTOS supports software download and configuration online, that is convenient for camera updating and management
• Support Smart Phone, 3G phone or Iphone Control and Surveillance Support Firefox Browser (optional)

Specification

• Sensor: ¼" Color CMOS Sensor
• Resolution: 640 x 480 Pixels
• Lens: f: 6mm, F 2.0 (IR Lens)
• Viewing Angle: 60 Degree
• Minimum Illumination: 0.5Lux @ F2.0
• Video/Image Setting
• Video Compression: MJPEG Video Compression
• Video Frame Rate: 30fps (QVGA), 15fps (VGA)
• Resolution: 640 x 480(VGA), 320 x 240(QVGA)
• Light Frequency: 50Hz, 60Hz or Outdoor
• Video Parameters: Brightness, contrast
• Audio talk-back: Built-in Mic
• Communication
• System Interface: 10Base-T/100Base-TX Ethernet Port
• Supported Protocol: TCP/IP,DHCP,SMTP,HTTP,DDNS,UPNP,PPPoE,FTP,DNS
•  Wireless LAN: Support wireless network (Wi-Fi/802.11/b/g)mobile
• WEP Encryption: Disable / 64 bit / 128 bit
• WPA Encryption: KIP / AES
• Physical / Environment
• Pan/Tilt Angle: Horizontal: 270 degree & Vertical: 120 degree
• Alarm Input: 1 Channel on/off input
• Alarm Output: 1 Channel relay output
• Power Supply: 5V DC/2A External Power Adapter
• Power Consumption: 6W (Max.)
• Operate Temperature :(0°C ~ 55°C)
• Storage temperature:(-25°C ~ 55°C)
• PC System Requirement
• CPU: 2.0GHZ or above
• Memory Size: 256MB or above
• Display Card: 64M or above memory
• Supported OS: Microsoft Windows 98/ME/2000/XP/Vista
