Feature:

• 5 Inch TFT display wired baby monitor+one 1/4 Sharp night vision CCD camera
• This wonderful product can help you monitor your children or elder when you are working or watching TV.You can also use it as normal surveillance system for home security.

Specification:

• Color CCD Camera (Model: DF-3102)
• Alloyed shell and water-proof designed for day and night use　
• Image pick-up device: 1/4" color CCD
• Color system: PAL/NTSC
• Horizontal resolution 420 TV lines
• Video output: 1.0Vp-p 75 ohm
• Power input : DC12V
• IP66 Waterproof resistance grade
• High intensity infrared night vision illuminators (Built In 12 IR on)
• External dimensinons: width 58mm X height 65mm X thickness 80mm
• 5 inches Digital LCD Color Monitor (Model: SP-M50)　
• Brightness: 480cd/m2 ,contrast: 150:1
• Super sharp high picture resolution: 960 (h) x 234 (v)
• Dot pitch: 0.107(h) x 0.319 (v)
• Color syetem: PAL/NTSC
• Video input: 1Vp-p one way
• Eight languages OSD menu: Chinese,English,Russian,German Arabic,etc.
• Picture turn up/down or turn left/right function
• Audio output: 0.3W (Max)
• Power consumption: DC12V
• External dimensinons: (W) 163mmX(H) 125mmX(D) 30.5mm　

Electrical & Hardware Accessories

• 　15 meter electrical cables (electrical outlet for aircraft )
• 　2m electrical connect cables
• 　Flat surface / in dash and universal monitor mounts
• 　Full function wireless remote controller
• 　Earphone
• 　DC12V  power supply adapter
•    User manual
