Highlights

• Support channel security by hiding live display
• Display the local record state and basic information
• Two level password control: administrator and common user
• The DVR supports to install one IDE HDD to record only
• Support to backup via USB to USB flash memory
• Support to backup remotely by network client
• Record modes: Manual operation, Sensor detection, Schedule Record and Motion detection
• Support HDD recycle, single channel playback, deleting and locking the record, remote playback in Network Client through LAN or internet
• Two record search mode: time search and event search
• 4 alarm inputs and 1 alarm output
• Support various PTZ protocols, various PTZ preset, remote PTZ control
• RS 485 communication port
• Support TCP/IP protoco
• Support remote DVR configuration
• Support static IP, dynamic IP (DHCP) and PPPOE
• On-time live surveillance, remote playback, remote backup
• Remote PTZ control and preset
• Support IE browser for network client software

Specification

• Video Input: 4-CH BNC inputs
• Audio Input: Audio in/out: 2CH/ 1CH
• Record Resolution: NTSC: 352(H) x 240(V), PAL: 352(H) x 288(V)
• Display Speed: PAL:100 fps NTSC: 120 fps

• Real Time: App. 4CH Full Motion Transmission
• Record Mode: Manual Operation, Sensor Detection, Schedule Record and Motion Detection
• Video Compression: H.264
• Multi-task: Monitoring/Recording/PTZ Control/Remote/Backup/Playback
• Motion Detection: Yes
• Storage: Support SATA HDD
• PTZ Control: RS485
• Operation System: Linux
• Language: Simplified Chinese, English
• Dimension: 350 x 320 x 70 mm
• Weight: 2.5kg
• Alarm I/O Port: Alarm Output: 1-Out(Programmable), Terminal
