Image Sensor |
| Style |
Bullet |
| Sensor |
CCD |
| Sensor Size |
1/3 Inch Color Sony CCD |
| Resolution |
420TVLine |
| Lens (mm) |
6 |
| Viewing Angle (Degree) |
67 |
| Minimum Illumination (Lux) |
0.5 |
|
Video Image/Audio Setting |
| Compression |
H.264 |
| Video Frame Rate (FPS) |
25 |
| Refresh Rate |
60HZ, 50HZ |
| Video Adjustment |
Auto Backlight Compensation, Contrast Adjustable, Auto White Balance, Brightness Adjustable |
| OSD |
Yes |
|
Communication&Interface |
| Network Interface |
RJ-45 10/100Mb self-adaptable Ethernet slot |
| Supported Protocol |
FTP, UPNP, HTTP, DHCP, DNS, PPPoE, DDNS, SMTP, TCP/IP |
| IP Mode |
Static IP address, Dynamic IP address |
| Alarm Action |
Email Photo, FTP Photo |
|
Physical/Environment |
| Environment |
Outdoor |
| Power Supply (V) |
12 |
| Power Consumption (W) |
12 |
| Operate Temperature (℃) |
—10℃-45℃ |
| Storage Temperature (℃) |
—20℃-65℃ |
| Humidity (%) RH |
90% |
| Size (L x H x W, mm) |
180*100*100 |
|
System Requirment |
| Supported Mobile Systems |
Android, Symbian, Windows Mobile, iPhone OS |
| Supported Operating Systems |
Microsoft Windows ME, Microsoft Windows Vista, Microsoft Windows 2000, Microsoft Windows 98, Microsoft Windows 7, Microsoft Windows XP |
| Supported Browers |
Google Chrome, Other Standard Browser, Firefox, IE |
| Client Software |
Yes |
|
Additional Features |
| Features |
Remote Access, Day Night, Dual Stream, Motion Detection, Waterproof |
| IR Night Vision Distance (m) |
50 |
| User Account Setting (Level) |
4 |
| Online User |
10 |
| Update Firmware |
Yes |
| Language |
Simplified Chinese, English |
|
What's in the box |
| What's in the box |
IP camera, English User manual, Screew, CD, Ethernet cable, Power adaptor |
