Ultra Low Price 4 Chanel H.264 CCTV DVR Kit with 4 Night Vision CMOS Cameras

Satisfaction Guaranteed

Order Option

Make the order

QTY:

Favorite 294

Product Details | Reviews | Q & A | Bulk Order Inquiry

Product Details

Key Features

Complete H.264 CCTV kit. suitable for both Domestic or Business applications. Comes complete with 4 colour Sony CCD cameras. with IR Enhanced Night vision. Backup Via USB. Remotely activate and View Via the Internet from anywhere. even supports live viewing via your Mobile !! Very simple DIY installation.

Highlights

Economical 4 Channel Real-time Standalone DVR System
Support Network Access
Support VGA Output
2pcs Indoor Camera&2pcs Waterproof Outdoor Camera
All-in-one Kit, convenient for the users

Specifications

Video/Audio Input
Video Compression	H.264
Video Input	4 Channel
Video Input Interface	BNC (1.0 Vp-p, 75Ω)
Audio Compression	G711A
Audio Input	1 Channel
Audio Input Interface	RCA
Video/Audio Output
Live View Resolution	NTSC:D1 (704 x 480)/PAL:D1 (704 x 576)
VGA Output	1280x1024
Recording Resolution	D1, CIF
Video Output (Channel)	1
Audio Output (Channel)	1
Synchronous Playback (Channel)	4
Dual Stream	Yes
Hard Disk Driver
Interface Type	SATA
Single Capacity	(Not include Hard disk)
Max Capacity (T)	unlimited
External Interface
Network Interface	RJ45 10M/100M/1000M Adaptive Ethernet Interface
USB2.0 Interface	2
Serial Interface	RS485
DVR - Additional Features
Support System	Android, iPhone iOS, Symbian, Microsoft Windows XP, Windows7, Mobile Pocket, Mobile, Microsoft Windows 2000
Language	Simplified Chinese, Italian, Deutsch, Thai, Traditional Chinese, Russian, España, Português, English
Remote Control	Yes
Mouse Control	Yes
Recording Mode	Alarm Recording, Motion Detection Recording, Schedule Recording, Manual Recording
Video saving	Internet, Hard Disk
Backup	U disk, Hard Drive
General
DVR - Power Supply	12
DVR - Power Consumption (W)	2
DVR - Operate Temperature (°C)	0-50
DVR - Humidity (%) RH	10-90%
DVR - Dimensions (L x W x D, mm)	26045234
Image Sensor
Sensor Type	CMOS
Sensor Size	1/4 Inch
Signal System	NTSC, PAL
Horizontal Resolution	420TVLine
Lens (mm)	6
Viewing Angle (Degree)	90
Minimum Illumination (Lux)	0
Physical/Environment
Camera - Power Supply	12
Camera - Power Consumption (W)	2
Camera - Operate Temperature (℃)	-20℃ - 50℃
Camera - Operating Humidity (%) RH	90%
Camera - Additional Features
Camera Type	IR Camera
Waterproof	Yes
Water Resistant	IP65
IR Distance (m)	25
S/N Ratio (dB)	52
Video Output	BNC 1.0Vp-p 75Ω
Backlight Compensation	Automatic
Automatic Gain Control	On/Off
Power Supply Parameters
AC Input(V)	100-240V
DC Output(V)	12
Cables Parameters
Length	10m/20m/30m
Connector	BNC, DC
What's in the box
What's in the box	1 20m Video Cable, 2 Indoor Camera, Software CD, Remote Control, 1 30m Video Cable, 2 10m Video Cable, 2 Outdoor Camera, DVR, Mouse

Photos

Learn More About This Product

Why should I Install My Own CCTV Security Surveillance Systems?

It is imperative in this day when crime rates are growing at an alarming rate to take a proactive approach to home security. CCTV Security Surveillance Systems may be just what you need to take your security to the next level. Closed Circuit Television (CCTV) cameras once only found to monitor banks, casinos, airports, military installations, and convenience stores are now made available to you at an affordable price. This means you can create property protection both indoors and outdoors like never before.

Typically, a complete surveillance kit will be made up of a series of cameras connected (wired or wireless) to a DVR (digital video recorder) which records those images and in turn displays those images on a monitor. In addition, most of our advanced DVRs are capable of being connecting to a network that can send your CCTV images to an outside internet ready computer or smart phone.

The mere presence of video surveillance cameras can help prevent crime, from a residential home invasion to business vandalism. Furthermore, it can help obtain the evidence you need if a crime does actually happen. Video surveillance has been helpful in the conviction of many criminals. Often, if your cameras are positioned right, you can not only get a good image of a trespasser, but can even track his or her movement with different camera set-ups. Don't let the criminal have the upper hand. Build your surveillance system today.

All-in-one CCTV DVR Kit: Installation Is Easier than You Think

Easy to use combination power/video cables are included and are plug-n-play ready for easy installation. This is a simple to setup Do-it-Yourself CCTV security camera system kit as followed.

Reasons to Choose All-in-one CCTV DVR Kit from LightInTheBox

High Quality with Global Standards Professional sourcing team from LightInTheBox knows how to identify the good from the bad, and every LightInTheBox.com product undergoes an extensive testing and quality control procedure, ensuring each and every item purchased meets global quality standards. LightInTheBox.com offers only the highest quality products, you could shop with confidence.	Lowest Prices Guaranteed As a China-based global online retailer, LightInTheBox.com has developed long lasting ties with factories, distributors and warehouses throughout the Chinese wholesale community. Eliminating unnecessary costs and delivering the lowest possible prices to customers worldwide, LightInTheBox.com is committed to providing high quality merchandise for less.
Convenient & Friendly Customer Service LightInTheBox.com offers excellent, comprehensive customer service every step of the way. Before you order, make real time inquiries through use of our live chat. Once you’ve made a purchase, our customer service representatives are always on-hand to answer questions through our website’s easy to use ticket system. Shop with confidence and save with LightInTheBox.com!	Fast & Reliable Delivery Around The Globe Partnering with internationally trusted logistic service providers such as DHL, EMS and UPS, LightInTheBox.com ships to over 200 countries around the world. A variety of expedited shipping methods means there's a convenient delivery option for every budget.
7-Day No Hassle Return Policy Regular in-stock items may be returned within 7 days of receiving your order for a refund of 70% of the item's price for any reason. For complete details visit our return policy page.	Specially Selected Just for You LightInTheBox provides various professional selections for you to choose and try to make purchasing your CCTV DVR Kits just a little simpler.

All-in-one CCTV DVR Kit from LightInTheBox : Specially Selected Just for You

CCTV Cameras: bullet or dome waterproof IR night vision cameras with various horizontal resolutions and numbers meet your needs.

Multiple channels DVR: DVR stands for digital video recorder, can record and store hundreds of hours of high resolution video (such as H.264). With some DVRs you can view, retrieve and backup digital video via a USB link to your computer or networking (iPhone supported). Some DVRs also offer a counter and motion detection feature.

Connecting Cables: To DIY your CCTV security surveillance systems, you need many connecting cables, and we provide sufficient numbers of cables with various length to meet your needs.

Accessories & Power Supply: sufficient essential accessories for you to install and 4 kinds of power supply's standard for you to choose.

Processing Time

"Ships in 24 hours": Processing Time is guaranteed to be shorter than 24 hours.
Typical Processing Time: 3 - 7 business days

Shipping Time

Expedited: 3-5 business days
Standard: 6-8 business days

We ship to over 200 countries worldwide!

Payment Methods

Credit Cards we accept:

Payment Services:

Share Your Experiences to Win the New iPad!

Submit a review between April 1-30 to automatically enter.
* Upload a product image for an iPad AND iPad case ! > See Details

Average rating:

Write a review

Recent Reviews

By Kamal Hettige
Verified Buyer
Apr 09, 2013

This prodect is value for mony. looks good too. only problem I am having is getting connected to DVR through my Iphone. overall I am very happy with the product. I will recomend for any one.

Was this review helpful?

(0)|(0)

Share to facebook

By myo
Verified Buyer
Mar 29, 2013

the kit arrived very quickly, I had to pay VAT but that was expected. I have tested it and I am really glad I ordered from Lightinthebox. very fast delivery and item is as described. also I really do like the night vision feature.

Thank you

Was this review helpful?

(0)|(0)

Share to facebook

By irfan nagi
Verified Buyer
Jan 21, 2013

this is very good item box with 4 camera but i have one problame when i get this delivery from hong kong they charge me VAT.they need to tell the customers who get from out of country should be together with price which one is on main page
thank you very much light inthebox

Was this review helpful?

(4)|(0)

Share to facebook

By Marika
Verified Buyer
Jan 09, 2013

Really good product. It is my first time to buy from lightinthebox and I am very pleased with the purchase. Thanks

Was this review helpful?

(0)|(0)

Share to facebook

By adnan amri
Verified Buyer
Dec 15, 2012

it's the best for use at home or ather plaes

Was this review helpful?

(1)|(0)

Share to facebook

By Chin Wa Go
Verified Buyer
Dec 02, 2012

Very fast delivery,received my order in Malaysia within 5 days after ordering. Tested out all the cameras for night and day recording. All giving very clear images and good colour contrasts.
One suggestion though, it would be very convenient to us users if you can incoperate a Hard disk together with this set as a whole system. It will save us the trouble to source around for a suitable HDD for the system. I think all us users would gladly pay for the extra cost for the HDD.
Thanks and regards,

Was this review helpful?

(3)|(0)

Share to facebook

By Dr W Alishah
Verified Buyer
Nov 05, 2012

Very please with the products and the prompt service

Was this review helpful?

(0)|(0)

Share to facebook

By Nuno Felix
Verified Buyer
Nov 01, 2012

Hi just to say that you are a very efficient company. I had a problem with a adapter and Lightinthebox resolve it very quickly. They are 100% excellent sellers. I will keep making new orders from you for sure.

Was this review helpful?

(0)|(0)

Share to facebook

By paul falzon
Verified Buyer
Sep 25, 2012

I like to thank you for good service you have and i like tell other people that you are a very trusty company,,,,,,,,,thanks again for your service.

Was this review helpful?

(1)|(2)

Share to facebook

By sagren
Verified Buyer
Jun 11, 2012

thank you for the promp service,

WELL DONE.

Was this review helpful?

(0)|(1)

Share to facebook

All| Faqs| Product description| Shipping or Payment| Customer service issue

Show all answers Hide all answers

Q: Cost of shipping to Ireland [South] Cost of shipping to ireland camera set up ByEamonn Redmond May 13, 2013

A:
Shipping cost varies based on weight of the order as well as shipping distance. Here is a link for your reference about how to calculate shipping cost:
http://www.lightinthebox.com/knowledge-base/c1229/a3018.html
Thank you for shopping with us:)

ByDale
May 13, 2013
Was this answer helpful?
(0)|(0)

Q: I am looking to buy caneras with sound recording Does the: Ultra Low Price 4 Chanel H.264 CCTV DVR Kit with 4 Night Vision CMOS Cameras, have sound recording ByGraham May 08, 2013

A:
Yes, its records does have sound. Thank you for shopping with us:)

ByDale
May 08, 2013
Was this answer helpful?
(0)|(0)

Q: which power adapter The package comes with two power adapters: 1 x 12V2A and 1X 12V2.5A. The output jacks fit both on the DVR and the cameras. The DVR says 12V input (but not how many amps). Which adapter should be used for the cameras, and which adapter for the DVR? Byjoris Apr 16, 2013

A:
Sorry for confusion caused. The 12V 2.5A one should connect the DVR while the 12V 2A one connect the cameras. Thank you for shopping with us:)

ByDale
Apr 16, 2013
Was this answer helpful?
(1)|(0)

Q: Can the system snap a picture and email it to my smartphone when motion detection is detected? I didnt see a comment specifying that it will perform this function. ByTawes De, USA Apr 05, 2013

A:
Yes, you can set this kit to send the picture for you once motion is detected. Thank you for shopping with us:)

ByDale
Apr 07, 2013
Was this answer helpful?
(0)|(0)

Q: What is the hard drive memory size on this product? Also what is the power source, 110V or 240V to conform to Australian electricity supply? ByDon Phillips Apr 02, 2013

A:
This kit doesn't have hard drive memory. You need to buy hard disk to save the record. You can also copy the record to U disk from the hard disk. It uses 12V power, you need to buy a power adapter for this kit. Thank you for shopping with us:)

ByDale
Apr 02, 2013
Was this answer helpful?
(0)|(0)

Q: I am looking to buy caneras with sound recording Does the: Ultra Low Price 4 Chanel H.264 CCTV DVR Kit with 4 Night Vision CMOS Cameras, have sound recording ByGraham May 08, 2013

A:
Yes, its records does have sound. Thank you for shopping with us:)

ByDale
May 08, 2013
Was this answer helpful?
(0)|(0)

Q: Can the system snap a picture and email it to my smartphone when motion detection is detected? I didnt see a comment specifying that it will perform this function. ByTawes De, USA Apr 05, 2013

A:
Yes, you can set this kit to send the picture for you once motion is detected. Thank you for shopping with us:)

ByDale
Apr 07, 2013
Was this answer helpful?
(0)|(0)

Q: What is the hard drive memory size on this product? Also what is the power source, 110V or 240V to conform to Australian electricity supply? ByDon Phillips Apr 02, 2013

A:
This kit doesn't have hard drive memory. You need to buy hard disk to save the record. You can also copy the record to U disk from the hard disk. It uses 12V power, you need to buy a power adapter for this kit. Thank you for shopping with us:)

ByDale
Apr 02, 2013
Was this answer helpful?
(0)|(0)

Q: Continuous Recording Does it have the "Continuous Recording Mode" what means that if the disk achieve almost full it starts to delete old videos automatically? So it has the time that the hdd supports. tks. ByMauricio Santos Apr 01, 2013

A:
Yes, if the card is full, the new record will cover the history record automatically so it will record continuously. Thank you for shopping with us:)

ByDale
Apr 01, 2013
Was this answer helpful?
(1)|(0)

Q: Where do you connect a hard drive too, I have a external hard drive for my pc which connects via usb, can i use this to record from the dvr direct from the usb port or is there a sata connection somewhere (couldn't see one on the photo of the back of the dvr). ByNigel Mar 28, 2013

A:
Yes, the video can be saved on hard drive or U disk. Please click on the third picture, you can see the back of this DVR kit. Scroll down the page, you can see a picture shows you the connection of this DVR. Thank you for shopping with us:)

ByDale
Mar 28, 2013
Was this answer helpful?
(0)|(0)

Q: Cost of shipping to Ireland [South] Cost of shipping to ireland camera set up ByEamonn Redmond May 13, 2013

A:
Shipping cost varies based on weight of the order as well as shipping distance. Here is a link for your reference about how to calculate shipping cost:
http://www.lightinthebox.com/knowledge-base/c1229/a3018.html
Thank you for shopping with us:)

ByDale
May 13, 2013
Was this answer helpful?
(0)|(0)

Q: Do you ship this to sri lanka?how much time it takes and what is the shipping cost to sri lanka? how much time it takes and what is the shipping cost to sri lanka? Byhasitha Jun 13, 2012

A:
Dear hasitha,
Yes, we can ship your order to Sri Lanka.
The shipping time and cost depend on the shipping methods you choose. Please refer to this link for more detailed information on delivery times:
http://www.lightinthebox.com/index.php?main_page=knowledgebase&pg=kb.page&chapter=6&id=1233
Shipping rate to Sri Lanka depends on the weight of the package, the distance to the shipping address, and the shipping method chosen. To get an idea of how much it will cost to ship to your country, add the items you want to your cart and scroll down to “Estimate Shipping Costs” tool. Using this feature is for your reference only and in no way obligates you to purchase.

BySmile
Jun 13, 2012
Was this answer helpful?
(0)|(0)

Q: Con que empresa de transporte realizan el envio? De donde lo envían? que empresa usan para hacer el envío? Bygonza Aug 29, 2012

A:
Estimado/a Cliente
Hola.
Gracias por su interés en LightInTheBox.
Sobre las formas de envío, puede aclarar en esta página.
http://www.lightinthebox.com/es/knowledge-base/c1039/a1659.html
Desde China.
Saludos
LightInTheBox

ByRebeca
Aug 29, 2012
Was this answer helpful?
(0)|(0)

Q: ich habe alles bezahlt versand sowie den artikel wieso so soll ich nochmals 36,24€ bezahlen ich habe alles bezahlt versand sowie den artikel wieso so soll ich nochmals 36,24€ bezahlen Byantje hennig Jul 30, 2012

A:
Hallo,
Sie zahlen 36,24 €, weil es Frachtversicherung Kurs.
Vielen Dank für Ihr Verständnis.

ByYolanda
Aug 02, 2012
Was this answer helpful?
(0)|(2)

Q: valor total y pagal wester union hola necesito el valor total al comprar 2 unidades de este producto de ultra bajo precio 4 chanel CCTV DVR H.264 kit con 4 cámaras de visión nocturna CMOS tambien necesito saber el valor de envio a Pais Chile Ciudad Concepcion codigo postal 4030000 Byivan silva May 01, 2012

A:
Estimado/a Cliente
Hola.
Gracias por su interés en LightInTheBox.
Aparte del valor del producto, se necesita pagar unos gastos de envío para este producto:

Para conocer los gastos de envío, visite esta página por favor:
http://www.lightinthebox.com/es/knowledge-base/?pg=kb.page&chapter=1037&id=2572
La normativa aduanera es muy dinámica y depende de cada producto y país, por lo que no podemos ofrecerle información detallada al respecto. Hay clientes que pagan la aduan y otros no.
Para conocer las poíticas de aduana, por favor visite esta página:
http://help.lightinthebox.com/es/index.php?pg=kb.page&chapter=1043&id=2592

Para conocer las formas de pago, visite esta página por favor:
http://www.lightinthebox.com/es/knowledge-base/c1041/a1280.html
Saludos
LightInTheBox

ByRebeca
May 01, 2012
Was this answer helpful?
(0)|(0)

A:
Sorry for confusion caused. The 12V 2.5A one should connect the DVR while the 12V 2A one connect the cameras. Thank you for shopping with us:)

ByDale
Apr 16, 2013
Was this answer helpful?
(1)|(0)

Q: How much extra, if any, will I have to pay to have all Four outdoor cameras? I want all four Outdoor CCTV cameras instead of two outdoor and two indoor dome cameras. Will I have to pay any extras? ByJon Contreras Mar 19, 2013

A:
Sorry that this item can't be customized into 4 outdoor waterproof cameras. We do offer some CCTV DVR which have 4 outdoor cameras. Please refer to the following link to find more options:
http://www.lightinthebox.com/index.php?main_page=advanced_search_result&inc_subcat=1&search_in_description=0&keyword=CCTV+DVR+4+outdoor+camera

ByDale
Mar 19, 2013
Was this answer helpful?
(0)|(0)

Q: Can h .264 not run without an additional hard disk? And if yes, how long time can it record for. I I cannot figure out to make it work, i tried to contact the support team which have provide my router, but he says that something must be wrong with the hard disk. when the program from the iPad ask for at port , is it the mobile port, http port or the third one? please help... Bytony Nov 28, 2012

A:
This DVR kit need to connect the hard disk to record the images . Thanks for your inquiry !

ByAlex
Nov 30, 2012
Was this answer helpful?
(0)|(0)

Q: Would like to check s the item easy to install on program and is the DVR come together with SATA HDD Would like to check s the item easy to install on program and is the DVR come together with SATA HDD ByKenneth Nov 12, 2012

A:
Thanks for your question.
Please kindly see that item is easy to install and it will come with a instruction in detail. We are sorry that the hard disk does not come together with the DVR.
Please check that one:
http://www.lightinthebox.com/particular-economical-all-in-one-4ch-dvr-kit-500g-hard-disk-h-264_p260874.html
Hope you enjoy shopping here.

BySmile
Nov 12, 2012
Was this answer helpful?
(0)|(0)

Q: what hard drive can i add to this h 264 network dvr please give me a part number or numbers to order i have recently purchased a h 264 network dvr from you and need to add a hardrive please refer me to a hardrive for this thank you Byrenee callandri Jul 21, 2012

A:
Dear Customer,
Hard drive with SATA port would be needed. It's like the drive in desk top computer. We're sorry that it's not available at our site.
Hope you enjoy shopping at www.lightinthebox.com!

BySmile
Jul 22, 2012
Was this answer helpful?
(0)|(0)

Ask a new question

Ultra Low Price 4 Chanel H.264 CCTV DVR Kit with 4 Night Vision CMOS Cameras #00269169

After Viewing This Item, People ultimately bought

Product Details

Key Features

Highlights

Specifications

Photos

Learn More About This Product

Why should I Install My Own CCTV Security Surveillance Systems?

All-in-one CCTV DVR Kit: Installation Is Easier than You Think

Reasons to Choose All-in-one CCTV DVR Kit from LightInTheBox

All-in-one CCTV DVR Kit from LightInTheBox : Specially Selected Just for You

Reviews

Recent Reviews

Q & A

Cost of shipping to Ireland [South]

I am looking to buy caneras with sound recording

which power adapter

Can the system snap a picture and email it to my smartphone when motion detection is detected?

What is the hard drive memory size on this product?

I am looking to buy caneras with sound recording

Can the system snap a picture and email it to my smartphone when motion detection is detected?

What is the hard drive memory size on this product?

Continuous Recording

Where do you connect a hard drive too,

Cost of shipping to Ireland [South]

Do you ship this to sri lanka?how much time it takes and what is the shipping cost to sri lanka?

Con que empresa de transporte realizan el envio?

ich habe alles bezahlt versand sowie den artikel wieso so soll ich nochmals 36,24€ bezahlen

valor total y pagal wester union

which power adapter

How much extra, if any, will I have to pay to have all Four outdoor cameras?

Can h .264 not run without an additional hard disk? And if yes, how long time can it record for. I

Would like to check s the item easy to install on program and is the DVR come together with SATA HDD

what hard drive can i add to this h 264 network dvr please give me a part number or numbers to order

Your Recent History

Join our community

Popular Pages:

Related Tags

Compare Products and Vote Now!

Hot Categories

Subscribe To Our Newsletter:
